Infinian Technology Dealer, Distributor and Partner of Juniper SRX5000: SRX5400, SRX5600 and SRX5800 Series Firewall in India – Bangalore, Chennai for Price/Cost Call: 9739091119
Juniper SRX5000 Series are high-performance, scalable, and carrier-grade next-generation firewalls (NGFW) designed for large enterprises, data centers, and service providers. They provide advanced threat protection, high throughput, and modular scalability.
Key Features
| Feature | SRX5400 | SRX5600 | SRX5800 |
|---|---|---|---|
| Form Factor | 5 U chassis | 8 U chassis | 16 U chassis |
| Max Firewall Throughput | Up to 960 Gbps | Up to 1.44 Tbps | Up to 2.3 Tbps |
| Max IPSec VPN Throughput | Up to 135 Gbps | Up to 270 Gbps | Up to 420 Gbps |
| Concurrent Sessions | 120 million | 240 million | 345 million |
| Max Security Policies | 2 million+ | 4 million+ | 6 million+ |
| SPC Slots | 2 | 4 | 6 |
| IOC Slots | 2 | 6 | 12 |
| Power Supply | Redundant, Hot-swappable | Redundant, Hot-swappable | Redundant, Hot-swappable |
🔰 Juniper SRX5000 Series Overview
| Model | Max Firewall Throughput | Threat Prevention Throughput | Max VPN Throughput | Slots |
|---|---|---|---|---|
| SRX5400 | Up to 2 Tbps | Up to 400 Gbps | Up to 200 Gbps | 5 |
| SRX5600 | Up to 3 Tbps | Up to 600 Gbps | Up to 300 Gbps | 7 |
| SRX5800 | Up to 4+ Tbps | Up to 800 Gbps+ | Up to 400 Gbps | 11 |
⚡ Actual performance depends on the installed Service Processing Cards (SPCs) and I/O Cards (IOCs).
🧰 Key Features
- ✅ Modular Architecture: Customize performance & port density using SPCs and IOCs.
- 🔐 Next-Gen Firewall Capabilities: App control, IPS, URL filtering, SSL/TLS inspection (incl. TLS 1.3)
- 🛡️ Advanced Threat Prevention (ATP): Real-time malware protection, C2 detection via Juniper ATP Cloud
- 🔄 High Availability (HA): Active/Passive and Active/Active with session sync
- 📶 Secure SD-WAN support
- 🧠 AI-driven Security: Full integration with Mist AI and Security Director Cloud
- 🔗 Multi-Tenant Support: Logical system partitioning
- 🧱 Scalable Zero Trust Architecture
🧩 Hardware Architecture
| Component | Description |
|---|---|
| SPC (Service Processing Card) | Handles firewall, VPN, IPS processing |
| IOC (I/O Card) | Provides Ethernet/optical interfaces (1/10/40/100GbE) |
| Switch Fabric (SFB) | High-speed interconnect between cards |
| Routing Engine (RE) | Manages control and management plane |
| Chassis Options | 5U (SRX5400), 8U (SRX5600), 16U (SRX5800) |
| Power Supply | Fully redundant, hot-swappable AC or DC |
📦 Scalability
- 🔄 Add more SPCs to boost processing performance
- 🔌 Add IOCs for higher port density (1G, 10G, 40G, 100G)
- 🧱 Scale up from 20 Gbps to multiple terabits
🔐 Security Features
- Unified Threat Management (UTM): Combines antivirus, antispam, web filtering, and content security
- Intrusion Prevention System (IPS): High-throughput detection and blocking of malicious traffic
- Advanced Threat Prevention (ATP): AI-powered zero-day threat detection and sandboxing
- AppSecure: Application visibility and control for over 4,800 apps
- GeoIP & botnet protection: Integrated threat intelligence via Juniper Spotlight Secure
🧱 Modular Architecture
- Service Processing Cards (SPCs): Handle all security services; scalable by adding more cards
- I/O Cards (IOCs): Provide flexible connectivity options including 1GbE, 10GbE, 40GbE, and 100GbE
- Routing Engine (RE3): High-performance control plane with TPM module for secure boot
- System Control Board (SCB4): Enables up to 480 Gbps throughput per slot
The Juniper SRX5000 Series includes models like the SRX5400, SRX5600, and SRX5800—designed for large enterprises, data centers, and service providers. In India, pricing varies widely based on configuration, licenses, and vendor, but here’s a general overview:
💰 Price Range in India
| Model | Approx. Starting Price (INR) | High-End Configurations |
|---|---|---|
| SRX5400 | ₹2,50,000+ | ₹5,00,000–₹8,00,000 |
| SRX5600 | ₹5,00,000+ | ₹10,00,000+ |
| SRX5800 | ₹8,00,000+ | ₹15,00,000+ |
These prices can go higher depending on:
- Advanced threat prevention subscriptions
- Support plans
- Custom hardware modules (SPC/IOC slots)
⚙️ Key Specs Across the Series
- Firewall throughput: Up tVPN throughput: Up to 420 Gbps
- Concurrent sessions: Up to 345 million
- Form factor: Modular chassis (5U to 16U)
- Power: Redundant, hot-swappable supplies
- Security services: UTM, IPS, ATP, AppSecure
These beasts are built for serious traffic and security demands. If you’re deploying in a carrier-grade or hyperscale environment, the SRX5000 series is one of Juniper’s most scalable options.
